Engine Power (HP): 290
Actual Load (T): 20-30
2.Standard configuration chassis, sub frame, van body side 6mm bottom 8mm, domestic middle lifting hydraulic cylinder Ф198, common steel, two longitudinal beams, rectangular van body, single door
3.Laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
|
Model |
ZZ3257M3847W |
|
|
Cab |
Model |
HW76 |
|
Type |
Extended cab, single sleeper, up and down, front and rear adjustable steering wheel, VDO instrument and control module, double locking structure seat belt, outer sun shield |
|
|
Engine |
Model |
WD615.87 |
|
Rated power kW/rpm |
213/2200 |
|
|
Maximum torque Nm/rpm |
1160/1100-1600 |
|
|
Displacement L |
9.726 |
|
|
Type |
Inline, six-cylinder, two-valve, supercharged intercooler, rear turbocharger |
|
|
Clutch |
Φ430 diaphragm spring clutch, hydraulically assisted by gas. WD615.62, WD615.87 comes standard with 430C, WD615.69 comes with 430B, WD615.47 comes with 430A |
|
|
Transmission |
HW series of 10-speed transmission, transmission-based, secondary box structure, the main box double shaft, deceleration of the planetary box, with power take-off. WD615.62, WD615.87, WD615.69 comes standard with HW15710, WD615.47 comes with HW19710 |
|
|
Front axle |
HF9 drum type, rated load 9 tons |
|
|
Rear drive axle |
HC16 double-stage deceleration (central deceleration + wheel deceleration), speed ratio: standard 5.73, optional 4.8 |
|
|
Suspension |
The front and rear suspensions are leaf springs, the front suspension is equipped with a shock absorber and a lateral stabilizer, and the rear suspension type is a disconnected balance suspension with a lateral stabilizer. |
|
|
Steering system |
ZF8098 direction machine, ZF steering oil pump, system pressure 18MPa |
|
|
Braking System |
Service brake: Double-circuit pneumatic brake; Parking brake: spring energy storage air brake; Auxiliary brake: Engine exhaust brake. Optional engine EVB, ABS and automatic clearance adjustment arm. |
|
|
Electrical system |
Voltage: 24V; Generator: 1540W; Starter: 24V, 7.5kW; Battery: 2×12V/165Ah |
|
|
Tires |
12.00-20; Optional 11.00-20 |
|
|
Fuel tank capacity L |
300 |
|
|
Service quality (vehicle/chassis) kg |
12200/8690 |
|
|
Total mass kg |
25000 |
|
|
Rated contained mass kg |
12670; Optional 12470 |
|
|
Dimension(Lx W xH)mm（unloaded） |
8545×2496×3170;3386(Front top) |
|
|
Chassis dimensions (length × width × height) mm |
7575×2496×2985 |
|
|
Wheelbase mm |
3825+1350 |
|
|
Front suspension/rear suspension (vehicle/chassis) mm |
1500/（1870/900） |
|
|
Track (front/back) mm |
2022/1850 |
|
|
Minimum ground clearance mm |
314 |
|
|
Approach angle/departure angle (whole vehicle/chassis) ° |
19/（23/50） |
|
|
Maximum speed km/h |
75 |
|
|
Maximum climbing ability % |
≥50 |
|
|
Minimum turning diameter m |
17 |
|
|
Container size (length × width × height) mm |
5600×2300×1200 |
|
