Engine: Chinese CA498
Diesel Type
FD25Tdiesel forklift is designed and manufactured for lifting and transporting cargoes. In consideration of exhaust gas emission and noise problem, it is usually suitable for outdoors, workshops or other places with not special requirements for exhaust gas emission and noise. This diesel powered forklift truck is configured with diesel engine that enjoys the advantages of good performance, strong overload ability, powerful long-time working capacity, fast speed and low fuel cost. The FD25Tdiesel forklift is available with the capacity of 2000 kg, advanced hydraulic and cooling system. VOSTOSUN diesel powered forklift trucks have obtained 13 patent certificates. Additionally, our company belongs to national level high-tech enterprise and is the engineering and technological research center of industrial forklift truck. Our company has received ISO9000 certificate and CE certificate.
Optional Engine
FD20,FD25: Chinese A490,Chinese CA498,Isuzu C240,Mitsubishi S4S,Yanmar 4TNE92
Features
· With unique mast and overhead guard design, FD25Tdiesel forklift owns good visibility and makes drivers safer to drive.
· Adopting an air spring device, the engine hood can be opened and closed effortlessly. Therefore, this diesel powered forklift truck is easy to maintain and repair.
· VOSTOSUN FD25Tdiesel forklift adopts high-performance air intake system and high capacity silencer to reduce noise.
· This forklift truck can be equipped with different kinds of diesel engines.
· Built-in inclined oil cylinder provides much wider driving space.
· The integrated operation system makes the 2T diesel powered forklift truck easy to manipulate.
Main Parts
VOSTOSUN FD25Tdiesel forklift consists of engine, transmission, operating control device, working device, hydraulic system and electric system. The engine, as the power unit of the forklift truck, can convert the thermal energy into mechanical energy. The transmission equipment includes clutch, gearbox, main transmission, differential mechanism and axle shaft.
Operation Attentions of VOSTOSUN FD25TDiesel Forklift
Customers should fully know the working environment, the maximum load and the maximum lifting height of the 2T diesel powered forklift truck, and then choose the appropriate models and configurations.
Packaging and Transportation
Shipping By Container.
|
SPECIFICATION |
Item |
FD20T |
FD25T |
|
|
Load capacity |
kg |
2000 |
2500 |
|
|
Load center |
mm |
500 |
||
|
DIMENSIONS |
Max. lifting height(VM300) |
mm |
3000 |
|
|
Free lift(VM300) |
mm |
160 |
||
|
Fork size (L×W×T) |
mm |
1070*122*40 |
||
|
Overall length(without fork) |
mm |
2460 |
2530 |
|
|
Total width |
mm |
1150 |
||
|
Mast height (fork lowering) |
mm |
1995 |
||
|
Overall height fork raised |
mm |
4030 |
||
|
Height to head guard |
mm |
2120 |
||
|
Truck weight |
kg |
3330 |
3670 |
|
|
TIRES |
front/rear |
2/2 |
||
|
front axle |
7.00-12-12PR |
|||
|
rear axle |
6.00-9-10PR |
|||
|
ENGINE |
Model |
ISUZU C240 |
Chinese CA498 |
|
|
Rated power |
kw/rpm |
34.3/2500 |
42/2450 |
|
|
Rated torque |
Nm/rpm |
138/1800 |
190/1800 |
|
|
Number of cylinders |
4 |
4 |
||
|
Dislacement |
L |
2.369 |
3.168 |
|
|
Item |
FD20T |
FD25T |
||
|
Load capacity |
kg |
2000 |
2500 |
|
|
Load center |
mm |
500 |
||
|
DIMENSIONS |
Max. lifting height(VM300) |
mm |
3000 |
|
|
Free lift(VM300) |
mm |
160 |
||
|
Fork size (L×W×T) |
mm |
1070*122*40 |
||
|
Overall length(without fork) |
mm |
2460 |
2530 |
|
|
Total width |
mm |
1150 |
||
|
Mast height (fork lowering) |
mm |
1995 |
||
|
Overall height fork raised |
mm |
4030 |
||
|
Height to head guard |
mm |
2120 |
||
|
Truck weight |
kg |
3330 |
3670 |
|
|
TIRES |
front/rear |
2/2 |
||
|
front axle |
7.00-12-12PR |
|||
|
rear axle |
6.00-9-10PR |
|||
|
ENGINE |
Model |
ISUZU C240 |
Chinese CA498 |
|
|
Rated power |
kw/rpm |
34.3/2500 |
42/2450 |
|
|
Rated torque |
Nm/rpm |
138/1800 |
190/1800 |
|
|
Number of cylinders |
4 |
4 |
||
|
Dislacement |
L |
2.369 |
3.168 |
|
