- Model range :Φ1.5×15m-Φ3.3×40m
- Production Capacity:2-36t/h
- Technical Features:Cooling the clinker (1000-1300℃) Discharged from Rotary Kiln to below 200℃ And im
The Description and Function of Monocula Cooler:
Cooler is one of the important machines of the rotary kiln system and its functions are to cool the clinker from the rotary kiln from 1000-1300℃ to below 200℃ and to improve the quality and grindability of the clinker.
The Advantages and Benefits of Rotary Drum Cooler:
This equipment can fully suck the air that is used for cooling the materials as secondary circulation air, thus improving the thermal efficiency of the kiln, and in addition, it has the features of simple structure, high running rate and convenient operation and maintenance, so that is very suitable for small-sized cement plant.
This equipment can fully suck the air that is used for cooling the materials as secondary circulation air, thus improving the thermal efficiency of the kiln, and in addition, it has the features of simple structure, high running rate and convenient operation and maintenance, so that is very suitable for small-sized cement plant.
Clinker with high temperature goes into the cooler through the feeding device, and the cooler will rotate to drive the materials to conduct heat exchange with the air, and with the constant rotation of the kiln according to the designed inclination and rotating speed, the materials will also periodically roll and move forward inside the kiln, so that the raw materials are send from the feeding end to the discharging end and cooled to below 200℃ in the time period when the materials go through the rotary kiln.
|
Spec./m |
Shell Cubage |
Capacity |
Installation |
Highest Inlet |
Main Motor |
Weight |
|
Φ1.2×8.0 |
9.0 |
1.9～2.4 |
3～5 |
700～800 |
7.5 |
9 |
|
Φ1.2×10 |
11.3 |
2.4～3.0 |
3～5 |
700～800 |
7.5 |
11 |
|
Φ1.5×12 |
21.2 |
4.5～5.7 |
3～5 |
700～800 |
15 |
18.5 |
|
Φ1.5×14 |
24.7 |
5.3～6.6 |
3～5 |
700～800 |
15 |
19.7 |
|
Φ1.5×15 |
26.5 |
5.7～7.1 |
3～5 |
700～800 |
15 |
20.5 |
|
Φ1.8×12 |
30.5 |
6.5～8.1 |
3～5 |
700～800 |
18.5 |
21.5 |
|
Φ1.8×14 |
35.6 |
7.6～9.5 |
3～5 |
700～800 |
18.5 |
23 |
|
Φ2.2×12 |
45.6 |
9.7～12.2 |
3～5 |
700～800 |
22 |
33.5 |
|
Φ2.2×14 |
53.2 |
11.4～14.2 |
3～5 |
700～800 |
22 |
36 |
|
Φ2.2×16 |
60.8 |
13.0～16.2 |
3～5 |
700～800 |
22 |
38 |
|
Φ2.4×14 |
63.3 |
13.5～16.9 |
3～5 |
700～800 |
37 |
45 |
|
Φ2.4×18 |
81.4 |
17.4～21.7 |
3～5 |
700～800 |
37 |
49 |
|
Φ2.4×20 |
90.4 |
19.3～24.1 |
3～5 |
700～800 |
45 |
54 |
|
Φ2.4×22 |
99.5 |
21.2～26.5 |
3～5 |
700～800 |
45 |
58 |
|
Φ2.6×24 |
127.4 |
27.2～34.0 |
3～5 |
700～800 |
55 |
73 |
|
Φ3.0×20 |
141.3 |
30.1～37.7 |
3～5 |
700～800 |
75 |
85 |
|
Φ3.0×25 |
176.6 |
37.7～47.1 |
3～5 |
700～800 |
75 |
95 |
|
Φ3.2×25 |
201 |
42.9～53.6 |
3～5 |
700～800 |
90 |
110 |
|
Φ3.6×28 |
285 |
60.8～76.0 |
3～5 |
700～800 |
160 |
135 |
|
Shell |
Inside |
Inside |
Shell |
Shell |
Shell |
Lifting |
Highest |
Dimensions |
|
Φ1.5×15m |
1500 |
500 |
15 |
20.27 |
3-5% |
Lifting form |
850 |
16.2×2.7×2.7 |
|
Φ1.5×17m |
17 |
22.97 |
18.2×2.7×2.7 |
|||||
|
Φ1.5×19m |
19 |
25.68 |
20.0×2.9×2.9 |
|||||
|
Φ1.8×21m |
1800 |
650 |
21 |
35.91 |
3-5% |
Lifting form |
850 |
22.5×2.7×2.7 |
|
Φ1.8×23m |
23 |
39.33 |
24.5×2.9×2.9 |
|||||
|
Φ1.8×25m |
25 |
42.75 |
26.5×2.9×2.9 |
|||||
|
Φ2.2×21m |
2200 |
800 |
21 |
58.10 |
3-5% |
Lifting form |
850 |
---- |
|
Φ2.2×23m |
23 |
63.61 |
||||||
|
Φ2.2×25m |
25 |
69.15 |
