- Opeartion Mass: 6ton
- Static Linear Load: 232.4 N/cm
- Centrifugal Force: 55KN
highways, as well as the compaction of the narrow road surfaces such as groove foundation with width above 1.5m, building construction, pipeline backfill and stadium.
1.Hydraulic vibration and oscillation, great centrifugal force and high compactness.
2.This roller has articulated frame, hydraulic steering, small turning raming radius and flexible drive.
3.Anticorrosive spray water system and fool capacity water tank and electric pressurized sprinkler.
4.Shock-proof sock absorber for long life and operate comfortable.
5.Close performance is extremely fine and work close building.
6.Secure hydralic brake.
|
MODEL |
UNIT |
VSRC6 |
VSRC6D |
|
Operating mass |
Kg |
6000 |
6000 |
|
Static linear load |
N/cm |
232.4 |
232.4 |
|
Drum diameter |
mm |
950 |
950 |
|
Rolling width |
mm |
1320 |
1320 |
|
Centrifugal force |
kN |
55 |
|
|
Centrifugal Movement |
KN.m |
|
20.6 |
|
Oscillation frequency |
Hz |
46 |
43 |
|
Oriental vibration amplitude |
mm |
0.62 |
|
|
Oscillation amplitude |
|
|
0.6 |
|
Travel speed(I,II) |
km/h |
2.5/7.5 |
2.5/7.5 |
|
Grade ability |
% |
>20 |
>20 |
|
Engine |
|
498BG |
498BG |
|
Engine speed |
r/min |
2200 |
2200 |
|
Engine power |
kW |
42 |
42 |
|
Overall dimension |
mm |
3690x1600x2700 |
3690x1600x2700 |
|
Water tank capacity |
L |
435 |
435 |
