- Opeartion Mass: 4ton
- Vibration Drum width: 1350mm
- Centrifugal Force: 40KN
1.Full hydraulic drive, reliable performance, safety.
2.CVT(continuously variable transmission), it is very easy to change the travel speed freely.
3.Hydraulic vibration, with powerful centrifugal force and excellent compaction density.
4.Hydraulic articulated steering, flexible outstanding performance.
5.High operation efficiency with best economic performance.
6.Equipped with large-size hood as engine cover, more convenient for maintenance and repair.
7.Can be adopted in variable conditions, such like compaction on the asphalt pavement and compaction on the subgrade and fulling materials.
8.Tread-pattern driving tires as an option.
|
MODEL |
UNIT |
VSRS204H |
|
Overall dimension |
mm |
3935X1500X2515 |
|
Operating mass |
Kg |
4000 |
|
Travel speed |
Km/h |
0-6.3 |
|
Rated power/Model |
KW |
25/ZN390Q |
|
Rated speed |
r/min |
2600 |
|
Ground clearance |
mm |
260 |
|
Grade ability |
% |
25 |
|
Turning angle |
° |
30 |
|
Vibration amplitude |
mm |
0.4 |
|
Vibration frequency |
Hz |
45 |
|
Centrifugal force |
kN |
40 |
|
Vibration drum width |
mm |
1350 |
|
Wheel base |
mm |
1820 |
|
Turning radius |
mm |
4000 |
|
Water tank capacity |
L |
160 |
