1.Max. jib length: 70m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 30 meters.

2.Max. lifting capacity 12t.

3.With PLC control, the electrical control system enjoys better reliability and safety. Produced by professional manufacturers with advanced foreign technology, the electrical elements feature service lives that are 3 or 4 times longer than that of domestic products, less faults, easy maintenance and repair as well as reliable operation.

XGT7021
Items	Mechanism	Speed（m/min）		Rope capacity	Motor（Kw）
Hoist mechanism	55JLF30A	2 multiplying power	0-90	695M＞695M*	55
		4 multiplying power	0-45
Trolleying mechanism	6JXF5	0-63m/min			5.5
Slewing mechanism	JH12CT6	0-0.66r/min			2×7.5
Travelling	RT	0-25m/min			4×4
Main Supply	380V（±10%）/50Hz*
Gross Power(Excluding climbing and travelling)：75.5Kw
