1.Performance parameters and technical indexes reach both domestic and international advanced level.

2.Max. jib length: 80m; Jib length under different assembling modes can decrease progressively by 5 meters and the Min. jib length is 40 meters.

3.Max. lifting capacity 16t.

XGT8020
Items	Mechanism	Speed（m/min）		Rope capacity	Motor（Kw）
Hoist mechanism	75JLF40	2 multiplying power	0-90	804M＞804M*	75
		4 multiplying power	0-45
Trolleying mechanism	7.5JXF8C	0-65m/min			7.5
Slewing mechanism	JH12CT6	0-0.65r/min			3×7.5
Travelling	RT	0-25m/min			4×5.2
Main Supply	380V（±10%）/50Hz*
Gross Power(Excluding climbing and travelling)：105Kw
