Performance Features

1.     Large Power

A.    The product has large lifting force and breakout force owing to the optimization design for the single rocker arm Z-form reversal mechanism.

B.    The single-phase 4-element twin turbine torque converter with reduced number of gear forms rational match with transmission gearbox and engine to assure large traction force.

C.    The product is configured with the Jingong 50 strengthened drive axle which has large bearing capacity.

D.    The adopted Weichai low speed engine of Landking Generation II is powerful.

E.     The box-type structure of the product has strong bearing capacity.

F.     the body of the efficient front loader is strengthened in the combination of single rocker arm Z-form reversal mechanism, strong front and rear frame as well as our 50 transmission assembly (including the torque converter).

2.     High Efficiency

A.    By using the design of medium wheelbase and centring arrangement, the product has high mobility and flexibility.

B.    Due to the function of automatically moving to the flat state of the working device, the action cycling time is short and the working efficiency is high.

C.    The dual pump confluence hydraulic system of the product can work with high efficiency and save energy.

D.    The product can accelerate faster owing to the match of our 50 planetary transmission gearbox and single-stage 4-element twin turbine torque converter.

5.     Higher Reliability

A.    Our 50 planetary transmission gearbox and drive axle works with high stability and reliability.

B.    The economical front loader is furnished with the high-level free maintenance accumulator to strengthen the working reliability and stability.

C.    It uses the reliable and durable electrical element, wire and sheath adopting the flame retardant material.

D.    The overall steel frame of the cab has high structural strength and reliability.

E.     The front of the cab is formed through the mold and the overall blanking for the floor plate elevates the reliability.

F.     The rear machine cover is constructed with the overall frame type to ensure good reliability.

G.    The Weichai engine of Landking Generation II performs excellently to strengthen the performance of the economical front loader.

a.     The Weichai engine can output large torque and ensure traction force. It is environment friendly by working with high efficiency and low

fuel consumption.

b.     The fuel system protector is available for service.

I. Under special weather and environment conditions, the fuel system protector can ensure the normal work when the engine is filled with the diesel of the same grade. Namely, under the environment with the temperature of or so, the product can still work normally after being added with the 0# diesel. II. The fuel system protector can achieve oil pumping and air exhaust to reduce the startup time and extend the service lifetime of the startup elements. III. The trustworthy dewater filter core is exploited for filtering the impurities and moisture to lower the failure rate of fuel system.

c.     The electromagnetic thermostat fan can actualize the automatic adjustment of the fan speed.

I.      The thermal equilibrium of the diesel engine can be improved and the replacement cycle for the cylinder liner, piston, piston ring and piston pin can be extended.

II.    The electromagnetic thermostat fan can effectively reduce the useless power consume of the fan to save the fuel.

6.     More Comfort

A The electromagnetic thermostat fan of the engine can reduce the vibration of the engine, contributing to the increase of the comfort.

B.    The interior decoration looks nice by adopting the composite material.

C.    The cab of the economical front loader is fitted with luxury interior and large space allowing for broad vision field.

D.    The operational devices are arranged rationally in the cab to facilitate the operation.

E.     Due to the 4-point elastic suspension and bi-directional shock absorption, the damping effect can outnumber 85%.

F.     The measures of noise reduction by using sound-absorbing material and sound insulation via the floor mats can weaken the reverberation in the cab to abate the fatigue of the operator.

7.     Diverse Configuration

The product can be configured with different working components to complete the diversified working requirements. The working device has different bucket capacities to fit for the ordinary arm and high dumping arm.

A.    Weichai Landking Generation-ll low speed engine and Jingong 50 strengthened axle

B.    Meritor drive axle

C.    Cooling or the cooling and heating air conditioner

Standard
No.	Item.		Parameter	Unit
			756K
1	Engine		Weichai WD10G220E23
2			162(220)	kw(hp)
2	Operating Weight		16800	kg
3	Rated Load		5000	kg
4	Bucket Capacity		2.7	m3
5	Dumping Height		3153	mm
6	Dumping Reach		1315	mm
7	Max.Traction Force		≥160	KN
8	Max.Breakout Force		≥170	KN
9	Overall Dimension	L*W*H	7750*2990*3410	mm
10	Boom Lifting Time		≤5.6	s
11	Total Cycling Time		≤11	s
12	Wheel Base		2910	mm
13	Min.Turning Radius	Outer Edge of Bucket	6670	mm
14	Traveling Speed	Forward I	0-11.5	km/h
15		Forward II	0-36	km/h
16		Reverse I	0-16	km/h
18	Fuel Tank Capacity		230	L
19	Hydraulic Oil Tank Capacity		270	L
